Cutting Tools
Read moreDuplex-CROSAL®-Plus
CROSAL®-Plus – That your tools withstand even highest temperatures
CROSAL®-Plus coating is eifeler’s next generation AlCrN based hard coating.
The new coating system is an advanced development of our well-established CROSAL® coating.
As a result of optimized process parameters and a tailor-made coating microstructure this versatile high-performance coating covers all key requirements:
- high oxidation resistance
- outstanding hot hardness
- excellent coating adhesion
Your plus in metal cutting
CROSAL®-Plus is perfectly suited for challenging applications within the fields of dry cutting,
punching and forming.
Applications
CROSAL®-Plus is especially suited for the following applications:
- Hobbing of alloy and stainless steels, cast iron and challenging materials
- Drilling and milling of alloy and stainless steels, cast iron and changeling materials
- Dry broaching of tough alloys
- Fine blanking
- Hot pressing
- Al die casting
Application Areas
Stamping & Forming
Read moreTechnical Information
| Hardness | 3.200 ± 300 HV |
| Max. temperature of operation | 1100 °C / 2012 °F |
| Coeff. of friction against steel | 0.45 |
| Coating thickness | 2-5 µm |
| Colour | slate-grey |
